With this series small footprint, multiple machines can be arranged side by side, meeting the needs of an automatic production line for mass production.

• Large slant-bed chip-removal design with strong coolant to remove all chips.
• The special square-steel-inlaid guideway design provides superior cutting rigidity.
• The steel-inlaid guideway with wear-resistant technology greatly dampens vibration and improves accuracy.
• Ultra-high precision spindle with runout accuracy of less than 0.003 mm (0.00012”).
• Assembly requirement is 0.002 mm (0.00008”).
• The labyrinth spindle provides the best protection against dust, water and chips.
• The super-heavy cutting servo turret design provides the best dynamic cutting rigidity and tool change stability.
• The whole machine is constructed with professional assembly fixtures to achieve the highest precision and uniform quality.
• Overall fixture design and processing procedure evaluation is included.

This Series is ideal for automation or cell manufacturing and the simplified fixture design is excellent for processing irregular shaped workpieces
